Engine
| Type | Air-cooled, four-stroke, 45° V-Twin | |
| Displacement | 1203 cc | |
| Bore & Stroke | 3.5 x 3.8 in. / 88.8 x 96.8 mm | |
| Compression Ratio | 10:1 | |
| Valve Train | OHV, two valves per cylinder, hydraulic adjusters | |
| Valve Adjustment | Self adjusting | |
| Carburetion | Dynamic Digital Fuel Injection (DDFI) | |
| HP/Torque | 101 hp @ 6000 rpm; 90 ft-lbs @ 5500 rpm | |
| Lubrication | Dry sump, 2.0 qt. (1894 cc) | |
| Battery | 12-volt, 19 amp-hour, SLA (Sealed Lead Acid) |
Drive Train
| Transmission | Five-speed, constant mesh | |
| Ratios | (1) 2.69, (2) 1.85, (3) 1.43, (4) 1.18, (5) 1.00 | |
| Primary Drive | Triplex chain; 1.6:1 | |
| Clutch | Wet, multiplate | |
| Final Drive | Kevlar® belt; ratio 2.26:1 |
Chassis
| Frame | Tubular perimeter chrome-moly frame with Uniplanar® powertrain vibration isolation system; Black, Nuclear Blue or Blazing Orange finish | |
| Wheelbase | 55.0 in/139.7 cm | |
| Rake / Trail | 24.5°, 3.8 in/9.7 cm | |
| Front Suspension | Showa® inverted forks with adjustable compression and rebound damping | |
| Rear Suspension | Aluminum arc swingarm; Showa extension type damper with adjustable compression damping, rebound damping and spring preload | |
| Front Wheel Travel | 4.7 in/11.9 cm | |
| Rear Wheel Travel | 4.6 in/11.7 cm | |
| Front Brake | Six piston caliper, 340 mm stainless steel floating rotor | |
| Rear Brake | Single piston caliper, 230 mm stainless steel rotor | |
| Front Wheel | 3-spoke cast, 3.5 x 17; Stardust Silver, Nuclear Blue or Blazing Orange finish | |
| Rear Wheel | 3-spoke cast, 5.0 x 17; Stardust Silver, Nuclear Blue or Blazing Orange finish | |
| Front Tire | Dunlop SportMax II Touring Radial, 120/70 ZR 17 D205F | |
| Rear Tire | Dunlop SportMax II Touring Radial, 170/60 ZR 17 D205 | |
| Seat Height | 29.5 in/74.9 cm | |
| Fuel Tank Capacity | 5.4 gal. (Low fuel light at .4 gal.)/ 20.4L (low fuel light at 1.5L) | |
| Miles Per Gallon <ETH> EPA Test Reg. | 45 City/53 Highway | |
| Gross Vehicle Weight Rating | 915 lbs./415 kg | |
| Dry Weight | 465 lbs./211 kg | |
| Load Capacity | 397 lbs./180 kg |
Instruments
Electronic speedometer, tachometer, odometer, tripmeter, clock, warning light for low oil pressure, indicators for high beam, turn signals, neutral, low fuel light and check engine light.
Warranty
12 months, unlimited miles
Colors
Carbon Black, Blue Streak, Volcano Grey
Optional Features
Buell P/M 3.5 x 17 front and 5.5 x 17 rear, polished spun aluminum wheels
Touring Equipment
High touring handlebars, color-coordinated saddlebags (deep or narrow) with fitted inner luggage, color-coordinated fairing lowers, fairing and underseat storage bags
Special Features
European passing lamp, spring-loaded rider foot pegs
All specifications are subject to change.
